TBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor Visuals

Product Categories
Topbright Creation Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor Visuals

  • 1
  • 2
  • 3

Brand Name : TBC

Model Number : E8-A

Certification : CE-EMC, CE-LVD, RoHS, ETL, FCC

Place of Origin : China

MOQ : 10sqm

Price : Negotiable

Payment Terms : T/T, Western Union, PayPal

Supply Ability : 10,000sqm/month

Delivery Time : 15-25days

Packaging Details : Wooden box

Pixel : 8mm

Scan : 1/4 Scan

LEDs : RGB SMD 3in1

Digital Processing : 16bits

Face : Single face

Maintenance : Front Service

Contact Now

Discover the TBC Outdoor SMD LED Display P8: A Marvel of Outdoor Display Technology

TBC Outdoor SMD LED Display P8: Revolutionizing Outdoor Visuals with Advanced Features

Outdoor LED screen Quick Details:
  1. Pixel Pitch: 8mm, offering a cost - effective yet high - quality visual solution for outdoor applications.
  2. SMD technology, delivering a Wide viewing angle of 160°/ 160°. This wide viewing angle ensures that the display can be seen clearly from different positions, making it suitable for crowded areas.
  3. IP rating: front: IP65/ rear: IP54. The high - level waterproof and dust - proof ratings protect the display from the elements, ensuring its long - term performance.
  4. RGB full color, refresh rate: 2,000:1, high contrast: 4,000:1. These features result in vivid and sharp images, making the content more appealing and engaging.
  5. Single face, front open, customized cabinet. The front - open design simplifies maintenance, and the customized cabinet can be designed to fit any installation space.
  6. 3 - year warranty, providing customers with long - term support and assurance.
Outdoor LED screen Description:
TBC offers a diverse range of SMD led displays, including both outdoor and indoor models. Our outdoor led billboards are designed to withstand the harshest outdoor conditions, while our indoor led video walls are perfect for creating immersive visual experiences. The pixel pitch options range from ultra - high - definition small - pitch displays to larger - pitch displays suitable for outdoor use. The TBC Outdoor SMD LED Display P8 is a prime example of our commitment to providing high - quality outdoor display solutions.
Outdoor LED screen Application:
The TBC Outdoor SMD LED Display P8 has a wide range of applications. In the advertising industry, it can be used to create eye - catching billboards that attract the attention of passers - by. In the media industry, it can be used for live event broadcasts, such as concerts and sports games. In educational institutions, it can be used for announcements and information dissemination. In entertainment venues like cinemas and concert halls, it can be used to display trailers, event schedules, and other important information.
Outdoor LED screen Features and Advantages:
  1. Build - in intelligent sensor: The intelligent sensor in the TBC Outdoor SMD LED Display P8 adjusts the brightness according to the ambient light. It also monitors the temperature and humidity, ensuring that the display operates optimally in all conditions.
  2. Good heat dissipation with fan cooling system: Outdoor displays are exposed to high temperatures, and the fan cooling system in the TBC Outdoor SMD LED Display P8 helps to dissipate heat effectively. This ensures the longevity and stability of the display.
  3. IP65 high - performance waterproof and dust resistance: The front - end IP65 rating makes the display highly resistant to water and dust. This means that it can be installed in areas with heavy rain, snow, or dust without any issues.
  4. Front - open design: The front - open design of the TBC Outdoor SMD LED Display P8 allows for easy maintenance. This is a significant advantage, especially for wall - mounted installations where rear access may be limited.
  5. SMD LEDs ensure large viewing angle: The SMD LEDs in the TBC Outdoor SMD LED Display P8 provide a large viewing angle, ensuring that the content can be seen clearly from different directions.

TBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor VisualsTBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor VisualsTBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor Visuals

Parameters:
Parameter Unit Value
Brightness nits 6000
Color temperature deg.k 3200 ~ 9300
Viewing angle - Horizontal deg. 160(+80/-80)
Viewing angle - Vertical deg. 160(+80/-80)
Cabinet weight kg 61
Cabinet width mm 1024
Cabinet height mm 1024
Cabinet depth mm 150
Cabinet area sq. m. 1.05
Cabinet material 　 Cold Steel
Aspect ratio 　 1:1
Ingress protection (Front/Rear) IP IP65/IP54
Operating temperature range deg. C - 20 to 50
Operating humidity range HR 10％ to 90％
Pixel type and configuration R/G/B SMD 3in1
Pixel pitch mm 8
Pixel matrix per cabinet 　 128x128
Pixels per cabinet 　 16384
Lines per meter 　 125
Pixels per sq. meter 　 15625
LEDs per sq. meter 　 15625
Recommended minimum viewing distance m 8
Colours 　 281trillion
Gray scale Levels 65536 levels per colour
Brightness control Levels 100
Digital processing bit 16
Frame rate Hertz 60
Display refresh rate Hertz 1920
Input voltage VAC 110/240
Input power frequency Hertz 50/60
Input power (max/avg) Watts per sq.m 1330/460
MTBF Hours ≥10000
Lifetime (50%Brightness) Hours ≥100000
Module brightness uniformity 　 ＜5％
Blind spot rate 　 ＜0.0001
Earth leakage current mA ＜2
Red wavelength nm 623
Green wavelength nm 525
Blue wavelength nm 470
Panel input format (with video processor) 　 VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV
Data interconnection 　 CAT6 cable/Fiber
Operating system 　 Windows(XP/Vista/7/8/10)
Control distance 　 Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers.
